SWITCHES
Switch Series
95
(continued from previous page)
Ordering Information
Springs: Copper alloy, plated
Lamp Terminals: Copper alloy, plated
Part Number
Guitar Switches
Circuitry
Description
Lamp Socket: Zinc, plated
Terminals: Copper alloy, plated,
straight solder lugs
Housing, Escutcheon, Knob,
Actuator and Switching Stacks
Insulation: Molded plastic
Specifications - PL Series
PUSH-LITE Switches Series and
PL Indicators
Contacts
Welded crossbar Gold Alloy,
rated at 2 amps., 200 watts
max., AC non-inductive load.
12010 SPST(NC)/SPST(NC)
12011 SPST(NC)/SPST(NC)
12012 SPDT(non-shorting)/SPST(NC)
12013 SPST(NC)/SPST(NC)
12014 SPST(NC)/SPST(NC)
12015 DPDT(NC)/DPDT(NC)
12016 SPST(NC)/SPST(NC)
12017 SPST(NC/SPST(NC)
Knobs
T12742
T12745
T127410
P2912
Broadcast Switches
Straight, nickel finish, riveted silver contacts
Straight, bright brass finish, riveted silver contacts
Right angle, nickel finish, welded silver contacts
Right angle, nickel finish, welded silver contacts
Right angle, black finish, welded silver contacts
Right angle, nickel finish, welded silver contacts
Right angle, bright brass finish, riveted silver contacts
Right angle, nickel finish, welded gold contacts
Black
White
Ivory
Amber
Electrical
6,000 Minimum Life (Gold
84206L
84306L
DPDT
SPDT(non-shorting) both sides
2 Position, locking
3 Position, locking
Alloy Contacts) per UL 1054.
Materials
Push-Lite Switch Assemblies:
Housing, Lifters, Switch Modules,
Barriers and Pushbuttons:
Molded Plastics
Contacts Springs: Phosphor
84312L DPDT both sides
84324L DPDT both sides
K131
PL106205 DPDT
PL206205 DPDT
PL106705 DPDT
PL206705 DPDT
3 Position, locking
3 Position, locking
Filter kit, 3 of ea. (amb, blu, grn, red, wht, and yel)
Momentary, single lamp
Momentary, twin lamp
Push-lock/Push-release, single lamp
Push-lock/Push-release, twin lamp
Bronze, Silver Plated
Lamp Terminals: Brass, Silver plated
See Next Page for Mechanical Drawings
Lamp Socket, Light Divider and
Yoke Assembly: Nickel Silver
Mounting Bracket and Retaining
Clips: Steel with iridescent
iridite over Cadmium Plating
Series PL Pushbuttons:
Housing, Color Filter Inserts and
Display Screens: High impact
thermoplastic
PL Indicators:
Housing: Molded glass filled
Plastics
Mounting Bracket: Steel, irides-
cent over cadmium Plating.
Lamp Retainer and Terminals:
Nickel Silver.
Display Screen (Pushbutton):
Molded Plastics.
5555 North Elston Avenue / Chicago, IL 60630
Phone: 773-792-2700 / Fax: 773-792-2129
